1.Material:Black iron wire ,Low carbon steel wire;galvanized wire zinc coated 10-40g/m2;hot dipped galvanized wire.Zinc coated 40-200g/m2
2.Opening size: 1/2",3/4",1",1 1/2",2",3",4"
3.Application: Welded Wire Mesh used as fencing, decoration and machinery protection material in construction, sports field, agriculture, mine, transport, lawn and various industrial fields.
Specification List of Hot Dipped Galvanized Welded Wire Mesh
Opening
Wire diameter
Inch
mm
BWG
1/4" x 1/4"
6.4mm x 6.4mm
22,23,24
3/8”x3/8”
9.5mm x 9.5mm
19,20,21,22
1/2" x 1/2"
12.7mm x 12.7mm
16,17,18,19,20,21,22,23
5/8" x 5/8"
16mm x 16mm
18,19,20,21,
3/4" x 3/4"
19.1mm x 19.1mm
16,17,18,19,20,21
1" x 1/2"
25.4mm x 12.7mm
16,17,18,19,20,21
1-1/2" x 1-1/2"
38mm x 38mm
14,15,16,17,18,19
1" x 2"
25.4mm x 50.8mm
14,15,16
2" x 2"
50.8mm x 50.8mm
12,13,14,15,16
Technical Note:
1.Standard roll length: 30m;width: 0.5m to 1.8m
2.Special sizes available at request
3.Packing: in waterproof paper in rolls. Custom packing available at request
