Razor Barbed Wire

Razor Barbed Wire

Type:Barbed Wire Coil
Wire Dia:0.9mm-3mm
Customise acceptable
Free sample
Product description: razor barbed wire can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders, with piecing and cutting razor blades mounted at the top of the wall, also t
INQUIRY

Razor barbed tape is a kind of modern security fencing materials fabricated with razor-sharp steel blade and high-tensile wire. Barbed Tape can be installed to achieve the result of frightening and stopping to the aggressive perimeter intruders, with piecing and cutting razor blades mounted at the top of the wall, also the special designs making climbing and touching extremely difficult. The wire and strip are galvanized to prevent corrosion. Currently, barbed tape has been widely used by many countries in military field, prisons, detention houses, government buildings and other national security facilities. Recently years, barbed tape has apparently become the most popular high-class fencing wire for not only military and national security applications, but also for cottage and society fence, and other private buildings.

Reference Type Number	Thickness	Wire Dia.	Barb Length	Barb width	Barb spacing
BTO-10	0.5±0.05	2.5±0.1	10±1	13±1	25±1
BTO-12	0.5±0.05	2.5±0.1	12±1	15±1	25±1
BTO-18	0.5±0.05	2.5±0.1	18±1	15±1	35±1
BTO-22	0.5±0.05	2.5±0.1	22±1	15±1	36±1
BTO-28	0.5±0.05	2.5	28	15	46±1
BTO-30	0.5±0.05	2.5	30	18	46±1
CBT-65	0.6±0.05	2.5±0.1	65±1	21±1	101±2

Outside Diameter	No. of Loops	Standard Length per Coil	Type	Notes
450 mm	33	8M	CBT-65	Single Coil
500 mm	41	10 M	CBT-65	Single Coil
700 mm	41	10 M	CBT-65	Single Coil
960 mm	53	13 M	CBT-65	Single Coil
500 mm	102	16 M	BTO-10,15,22	Cross type
600 mm	86	14 M	BTO-10,15,22	Cross type
700 mm	72	12 M	BTO-10,15,22	Cross type
800 mm	64	10 M	BTO-10,15,22	Cross type
960 mm	52	9 M	BTO-10,15,22	Cross type
